Carlo Galazzi DIA53S724100A AC Current Monitoring Relay, 10 to 100AC, 50 to 400Hz, 100mA, 1PH

• Manufacturer: Carlo Galazzi
• Model/Part#: DIA53S724100A
• Condition: New Surplus
• Type: AC Current / Contact Relay
• Relay Type: Solid State
• Current: 10 – 100A AC
• Frequency: 50 – 400 Hz
• Overvoltage Cat: III
• Max. Voltage: 40 VDC
• Max. Load: 100 mA
• Function: Current Monitor
• Mounting Type: DIN Rail
• Number of Phases: 1 Phase
• Secondary Current: 100 mA
• Secondary Voltage: 40 VDC
• Technology: Inductive
• Termination: Screw
• Length: 2.638In. (67 Mm)
• Width: 0.689 In. (17.5 Mm)
• NPN-PNP Open Collector, NO

Notes: This AC current relay is new surplus and is in excellent condition. Includes original box and instruction manual.
